Servo-controlled cutting, straightening, and trimming machine technical specifications

Cutting wire diameter: 2–6 mm

Cutting length range: 50 mm and above

Wire feeding speed: Adjustable speed 7–35 meters per minute

Straightening wire material: Ordinary carbon steel wire, stainless steel wire

Wire feeding frame: 800 × 300 × 600 mm

Wire feeding motor: 1.5 kW with reducer — Dongguan Wanxin

Straightening motor: 3KW-2P — Jiangsu Huasheng

Cutting servo motor: 0.75KW, 1500 RPM — Wuxi Xinjie

Guide rail module: Taiwan Seiko

Ball screw module: Taiwan Heqing

Number of wire feeding groups: 2 groups (4 pairs of wheels)

Control screen: Touchscreen

Number of straightening blocks: 8

Cutting motor: 1.0 kW (3000 RPM)

Wire material range: 2–6 mm (ordinary carbon steel) (stainless steel 2–4.5 mm)

Machine frame dimensions (L × W × H): 2670 × 710 × 1450 (mm)
